Solar Panel
Mono Crystalline Modules"
Model No. | Watt | Volt | VOC | Isc A | Vmp | Imp (Appx) | FF | No. of cells | Module Efficiency% (Min.) | Weight | Overall Dimension |
AMM40 | 40Wp | 12 | 21.9 | 2.49 | 18.3 | 2.19 | 0.75 | 36 | 17.00% | 3 | 520 X 560 X 30 |
AMM55 | 55Wp | 12 | 22.7 | 2.95 | 18.25 | 2.74 | 0.75 | 36 | 17.00% | 3.8 | 520 X 700 X 30 |
AMM80 | 80Wp | 12 | 21.85 | 4.37 | 18.25 | 4.1 | 0.75 | 36 | 17.00% | 5.3 | 520 X 1020 X 30 |
AMM110 | 110Wp | 12 | 22.8 | 6.65 | 18.8 | 5.85 | 0.75 | 36 | 17.00% | 7 | 670 X 1020 X 30 |
AMM160 | 160Wp | 12 | 22.8 | 9.52 | 18.81 | 8.5 | 0.75 | 36 | 17.00% | 10 | 670 X 1480 X 35 |
AMM200 | 200Wp | 12 | 26.5 | 9.95 | 21.05 | 9.5 | 0.75 | 42 | 17.00% | 12 | 990 X 1200 X 35 |
AMM270 | 270Wp | 12 | 37.9 | 9.73 | 30.51 | 8.85 | 0.75 | 60 | 17.00% | 16.5 | 990 X 1650 X 35 |
AMM330 | 330Wp | 24 | 42 | 9.98 | 36.75 | 8.97 | 0.75 | 72 | 17.00% | 20 | 990 X 1960 X 40 |
"Poly Crystalline Modules"
Model No. | Watt | Volt | VOC | Isc A | Vmp | Imp (Appx) | FF | No. of cells | Module Efficiency% (Min.) | Weight | Overall Dimension |
AMP40 | 40Wp | 12 | 22.72 | 2.35 | 19.04 | 2.1 | 0.75 | 36 | 14.00% | 4.1 | 500 X 620 X 30 |
AMP50 | 50Wp | 12 | 22.72 | 2.93 | 19.04 | 2.63 | 0.75 | 36 | 14.00% | 4.5 | 500 X 700 X 30 |
AMP60 | 60Wp | 12 | 22.72 | 3.52 | 19.04 | 3.15 | 0.75 | 36 | 14.00% | 4.9 | 500 X 875 X 30 |
AMP74 | 740Wp | 12 | 22.72 | 4.34 | 19.04 | 3.89 | 0.75 | 36 | 14.00% | 5.75 | 500 X 1020 X 30 |
AMP100 | 100Wp | 12 | 22.72 | 5.87 | 19.04 | 5.25 | 0.75 | 36 | 14.00% | 7.5 | 660 X 1020 X 30 |
AMP120 | 120Wp | 12 | 22.72 | 7.04 | 19.04 | 6.3 | 0.75 | 36 | 14.00% | 9 | 660 X 1285 X 35 |
AMP150 | 150Wp | 12 | 22.72 | 8.8 | 19.04 | 7.88 | 0.75 | 36 | 14.00% | 11.5 | 660 X 1485 X 35 |
AMP200 | 200Wp | 24 | 22.72 | 5.87 | 38.09 | 5.25 | 0.75 | 72 | 14.00% | 15.5 | 985 X 1325 X 40 |
AMP250 | 250Wp | 24 | 37.86 | 8.8 | 31.74 | 7.88 | 0.75 | 60 | 14.00% | 19.75 | 985 X 1640 X 40 |
AMP300 | 300Wp | 24 | 45.43 | 8.8 | 38.09 | 7.88 | 0.75 | 72 | 14.00% | 23 | 985 X 1950 X 40 |
AMSU INVERTER/PCUS
Grid-Tie Inverters
Grid-Tie inverters are simply inverters which are connected to the grid. Without getting too technical, these inverters produce a pure sine wave that is congruent with the AC waveform produced by the grid.
This allows you to send any unused, surplus solar electricity your system has generated back into the grid, which you may or may not receive a feed-in tariff for.
In the majority of cases and for most states, it’s a requirement that the inverter you install is grid-tied, whether it’s string, hybrid, or micro.
Off-Grid Inverters
Like standard string inverters, off-grid inverters are responsible for the conversion of DC electricity generated by your system’s panels into AC electricity that can be used by the appliances in your home.
Unlike standard string inverters however, they do not have the ability to export excess solar electricity into the grid. Off-grid inverters are used in either remote areas, or where the homeowner wants to separate entirely from the grid.
Batteries
Model No. | Nominal/Voltage | Capacity | Dimension (mm) | Warranty in Months | ||
Length | Width | Total Height | ||||
AmsuSolar Solar Batteries | ||||||
AMSB 40 | 12 | 40 AH | 409 | 173 | 230 | 36/48 |
AMSB 80 | 12 | 80 AH | 505 | 218 | 256 | 36/48 |
AMSB 120 | 12 | 120 AH | 503 | 190 | 407 | 36/48 |
AMSB 150 | 12 | 150 AH | 503 | 190 | 407 | 36/48 |
AmsuSolar Advance Solar Batteries | ||||||
AMSB A 40 | 12 | 40 AH | 409 | 173 | 230 | 60/72 |
AMSB A 80 | 12 | 80 AH | 505 | 218 | 256 | 60/72 |
AMSB A 120 | 12 | 120 AH | 505 | 218 | 256 | 60/72 |
AMSB A 150 | 12 | 150 AH | 505 | 218 | 256 | 60/72 |
